Parts List
Item Description Quantity
A Console 1
A-1 Console Fixing Screw 4
B Handlebar Assembly 1
B-1 Handlebar Assembly Endcap 1
B-4 Fore-Aft Adjustment Lever 2
B-13 Water Bottle Cage Fixing Screw 3
B-15 Water Bottle Cage Assembly 1
B-16 Water Bottle 1
B-17 Wire Harness 1
B-20 Handlebar Assy Endcap Fixing Screw 1
D Front Stabilizer Assembly 1
D-2 Leveling Foot Assembly 4
E Rear Stabilizer Assembly 1
F-16 Power Input Jack 1
F (L & R) Pedal, Clip & Strap Assembly (pair) 1
G Main Frame 1
G-6 Stem / Seat Post Adjustment Knob 2
H-1 Stabilizer Assembly Fixing Screw 8
H-2 Stabilizer Assembly Curved Washer 4
H-3 Stabilizer Assembly Flat Washer 4
H-4 Handlebar Assembly Fixing Screw 2
H-5 Handlebar Assembly Lock Washer 2
H-6 Handlebar Assembly Flat Washer 2
J Stem Assembly 1
K Assembly Hardware / Tool Kit 1
L Saddle 1
M-1 Emergency Stop Knob 1
N Power Supply/Adaptor 1
