Unpack the 910Ic from the carton. Please recycle.
Verify the carton contains all parts from the list.
Remove the blocking (the short section of tubing
installed at the factory to prevent damage to the
front frame during shipping) by removing the two
fixing screws shown in Figure 1 above. Discard this
piece.
Align the front stabilizer (D) with the receiver located in the
front of the frame, and loosely install four (4) H-1 bolts, two
(2) curved washers (H-2) and two (2) flat washers (H-3),
making sure that the correct shape of washers are installed on
their corresponding surface profile; i.e. flat washer on the flat
surface, etc. When all bolts have been inserted, tighten for
final installation.
Repeat this process for the rear stabilizer assembly (E).
