Automotive Circuit Probe & Breaker Finder Kit
3.2 Continuity Testing
While the circuit probeis in Resistance mode, using the probe tip and the auxilia ground
lead, continuity can be tested on wires and components attached or disconnected from
the vehide's electrical system.
When the probe tip is contacting a good ground, the LCD will indicate “0.0Ω” and green
LED will be on. A beep tone will sound (Figure 8)
Figure 8
In other cases, the LCD only indicates the resistance value, (Figure 9)
Figure 9
1.2K
