Automotive Circuit Probe & Breaker Finder Kit
Operating Temperature 0 to 60°C (32 to 140°F)
Storage Temperature -40 to 70°C (-40 to 185°F)
184 × 48 × 24mm/7.24 X 1.88 X 0.94 In
(Probe Length 72mm/2.83 In)
Dimensions (L × W × H)
2.2 Tool Kit Description
① Probe Tip - Contacts the circuit or component to be tested.
② Head Lights - lluminates dark work areas or work areas at night.
③ LCD Display - Indicates test results.
④ Red/Green Polarity Indicator - Identies positive, negative or open circuits. The RED
indicator lights up when the Probe Tip is contacting a positive circuit. The GREEN
indicator lights up when the Probe Tip is contacting a negative circuit.
⑤ Power Switch - Allows you to conduct a positive or negative batte current to the tip
for activating and testing the function of electrical components.
⑥ Mode Button - Selects the work mode: AC Voltage, DC Voltage, Resistance, Diode.
⑦ Adaptor - Connects to the batte.
⑧ Auxilia Ground Lead - Assists test as a ground lead.
