diatools V200 PRO - Important Safety Information; Using the Circuit Probe; 2.1 Specifications

1
Automotive Circuit Probe & Breaker Finder Kit
To prevent personal inju or damage to vehicles and/or the circuit probe,read this
instruction manual rst and obsee the following safety precautions whenever working
on a vehicle:
◆ Always peorm automotive testing in a safe environment.
◆ Wear eye protection that meets ANSI standards.
◆ Keep clothing, hair, hands, tools, test equipment, etc away from all moving or hot
engine pas.
◆ Operate the vehicle in a well ventilated work area: Exhaust gas are poisonous.
◆ Put blocks in front of the drive wheels and never leave the vehicle unattended while
running tests.
Use extreme caution when working around the ignition coil, distributor cap, ignition wires
and spark plugs. These component create hazardous voltage when engine is running.
◆ Put the transmission in PARK (for automatic transmission) or NEUTRAL (for manual
transmission) and make sure the parking brake is engaged.
◆ Keep a re extinguisher suitable for gasoling/chemical/electrical res nearby.
◆ Don’t connect or disconnect the circuit probe while the ignition is on or the engine
is running.
◆ Keep the tool d, clean, free from oil/water or grease. Use a mild detergent on a clean
cloth to clean the outside of the circuit probe, when necessa.
◆ When the power switch is depressed, batte current/voltage is conducted directly to
the tip which may cause sparks when contactiong ground or ceain circuits. Therefore
the tool should NOT be used around ammables such as gasoline or its vapors. The
spark of an energized tool could ignite these vapors. Use the same caution as you
would when using an arc welder.
1. Impoant safety information
2. Using the Circuit Probe
2.1 Specications
V200PRO Circuit Probe
Display TFT Color Display (168×128 dpi)
Operating Temperature 0 to 60°C (32 to 140°F)
Storage Temperature -40 to 70°C (-40 to 185°F)
External Power 12.0 or 24.0V Powered by Connecting to Vehicle Batte
Dimensions (L × W × H)
188 × 48 × 25mm(7.24 × 1.88 × 0.98 In)
(Cable Length 174mm/6.85 in)
Material Plastic Case
V200PRO Breaker Finder
Operating Voltage 9V (Powered by Internal 9V Batte)
Material Plastic Case + Bendable Metal Probe
