6
Automotive Circuit Probe & Breaker Finder Kit
While the circuit probein this mode, contact the probe tip to a circuit, then the LCD display
will read the DC voltage with a resolution of 0.1 volt. (Figure 2)
While the circuit probe in this mode, contact the probe tip to a circuit, then the LCD
display will read the Max. Voltage, the Min. Voltage and frequency.(Figure 3)
AC voltage
Figure 2
12.1V
While the circuit probe in this mode, contact the probe tip to a circuit, then the LCD display
will read the resistance between the tip and auxilia ground lead. (Figure 4)
Resistance
Figure 3
Max 17.9 Freq Hz
Min 0.3 50
