18.5. MESSAGES AND INDICATORS IN BATTERY-RUN SCALE
18.5.1.Messages and indicator of battery load
When operating, the battery scale shows its status in relation to the battery through:
1. Messages: which appear on the display to indicate status, changes in status, alarms, etc.
2.Battery Charge indicator: battery icon on the display made up of segments. The segments are: a
contour icon in the shape of a battery containing 3 segments to indicate the charge level.
The alarm messages display on the weighing screen only when it is in operation mode 2. (Cable disconnected,
scale on)
The battery indicator only displays on the weighing screen and disappears from all others. (Menus and
submenus, total cashier, discount on total, two forms of payment, etc.)
The battery-related messages that display on booting up the scale appear following the countdown and
will display for a few seconds the percentage of battery life in the following way:
“BATTERIE X%” where X is the battery level in %.
18.5.2.Messages and indication depending on operation status
See in the table below the different status of the battery charge indicator according to the level of charge
of the battery.
INDICATIONS OF BATTERY LEVEL
LEVEL
BATTERY CHARGE ICON ONLY BATTERY
Contour of battery icon
100
Charge>= 100%
Segments
Fixed
3 (optional blinking)
Contour of battery icon
90
100% > Charge >= 90%
Segments
ON
3 segments ON
Contour of battery icon
60
90% > Charge >= 60%
Segments
ON
2 segments ON
Contour of battery icon
30
60% > Charge >= 30%
Segments
ON
1 segment ON
Contour of battery icon
10
30% > Charge >= 10%
Segments
ON
All segments OFF
Contour of battery icon
0
Charge < 10 %
Segments
Blinking
All segments OFF
With the mains cable connected. The battery-shaped contour icon is switched on and the 3 segments
display a scan. ( )
