Hardware Specifications for Programmable Variant
If the module has the programmable secondary processor, add the following table values to the specifications
listed on page 7. For example, if the secondary processor is running at 20 MHz and the primary processor is in
receive mode then the new current value will be I
total
= I
r2
+ I
rx
= 14 mA + 9 mA = 23 mA, where I
r2
is the
runtime current of the secondary processor and I
rx
is the receive current of the primary.
Output source current 2 mA
Output sink current 2 mA
Total output current (for GPIO pins) 48 mA
Specificationsoftheprogrammablesecondaryprocessor
Optional Secondary Processor Specification
These numbers add to specifications
(Add to RX, TX, and sleep currents depending on
mode of operation)
Runtime current for 32k running at 20MHz +14mA
Runtime current for 32k running at 1MHz +1mA
Sleep current +0.5A typical
For additional specifications see Freescale Datasheet and
Manual
MC9SO8QE32
Voltage requirement for secondary processor to operate at
maximum clock frequency
2.4 to 3.6VDC
Minimum Reset Pulse for Programmable 100nS
Minimum Reset Pulse to Radio 50nS
VREF Range 1.8VDC to VCC
ElectricalSpecificationsforGPIOPins
GPIO Electrical Specification Value
