XBee‐PRO®900HP/XBee‐PRO®XSCRFModules
©2014DigiInternationalInc. 95
Receiver Sensitivity -106dBm -109dBm at 9600 baud -107dBm at 19200 baud
Power Requirements
Supply Voltage 3.0-3.6 VDC regulated 2.1 to 3.6VDC
Receive Current 65mA 26mA typical
Transmit Current 265mA 215mA at 24dBm
Power Down Current 50uA 2.5uA typical @3.3v
General
Frequency Range 902-928MHz (located in the 900MHz ISM Band)
Spread Spectrum Frequency Hopping
Network Topology Point-to-Point, Peer-to-Peer, Point-to-Multipoint
Channel Capacity 7 hop sequences share 25 frequencies
Board-level Serial Data Interface (S3B) 3V CMOS UART (5V-tolerant) 3V CMOS UART
Physical Properties
Module Board Size
1.297" x 0.962" x 0.215 (3.29cm x 2.44cm x 0.546cm)
Note: Dimensions do not include connector/antenna or pin lengths
Weight 5 to 8 grams, depending on the antenna option
Connector 2 rows of 10 pins, 22mm apart with 2mm spaced male Berg-type headers
Operating Temperature -40 to 85º C (industrial)
Antenna Options
Integrated Wire ¼ wave monopole, 3.25” (8.26cm) length, 1.9dBi Gain
RF Connector Reverse-polarity SMA or U.FL
Impedance 50 ohms unbalanced
Certifications
FCC Part 15.247 MCQ-XBEEXSC
MCQ-XBPS3B, or MCQ-XB900HP
(see preface)
Industry Canada (IC) 1846A-XBEEXSC
1846A-XBPS3B, or 1846A-XB900HP
(see preface)
Europe N/A
RoHS Compliant
Australia N/A C-Tick
Brazil N/A ANATEL 3727-12-1209
TableA‐01. XBee‐PROXSCRFModuleSpecifications
Specification XBee-PRO XSC (S3 Hardware) XBee-PRO XSC (S3B Hardware)
