Digi XBee

© 2014 Digi International Inc. 60
XBee/XBee-PRO
®
DigiMesh 2.4 User Manual
Addressing Discovery/ Configuration
NT
Node Discover Timeout. Set/Read the amount of time
a node will spend discovering other nodes when ND or DN
is issued.
0 - 0xFC
[x100 msec]
0x82
(130d)
NO
Network Discovery Options. Set/Read the options
value for the network discovery command. The options
bitfield value can change the behavior of the ND (network
discovery) command and/or change what optional values
are returned in any received ND responses or API node
identification frames.
Options include:
0x01 = Append DD value (to ND responses or API node
identification frames)
0x02 = Local device sends ND response frame when ND is
issued.
0x04 = Append RSSI (of the last hop for DigiMesh
networks) to ND or FN responses or
API node identification frames.
0-0x07 [bitfield] 0
CI
Cluster Identifier. Set/read application layer cluster ID
value. This value will be used as the cluster ID for all data
transmissions. The default value 0x11 (Transparent data
cluster ID)
0-0xFFFF 0x11
DE
Destination Endpoint. Set/read application layer
destination ID value. This value will be used as the
destination endpoint for all data transmissions. The
default value (0xE8) is the Digi data endpoint.
0-0xFF 0xE8
SE
Source Endpoint. Set/read the application layer source
endpoint value. This value will be used as the source
endpoint for all data transmissions. The default value
0xE8 (Data endpoint) is the Digi data endpoint
0-0xFF 0xE8
AT
Command
Name and Description
Parameter
Range
Default
AG
Aggregator Support. The AG command sends a
broadcast through the network that has the following
effects on nodes which receive the broadcast:
- The receiving node will establish a DigiMesh route back
to the originating node,
provided there is space in the rounting table.
- The DH and DL of the receiving node will be updated to
the address of the originating
node if the AG parameter matches the current DH/DL of
the receiving node.
- For API-enabled modules on which DH and DL are
updated, an aggregate
Addressing Update frame will be sent out the serial port.
Note that the AG command is only available on products
that support DigiMesh.
Any 64-bit
number
n/a
AT
Command
Name and Description
Parameter
Range
Default
