Chapter
3: Installation Over
view
11
Example Studio Setup with a Mixing Console
Example Studio Setup with a Mixing Console
Power Amp
and Speakers
Digital Inputs/Outputs
To DAT Recorder
DAT Recorder
ADAT
optical in/out
to ADAT
Instruments
Connected to Console
Analog
Audio
Outputs
Effects Devices
Digital Effects Device
(set to external sync)
Tape Returns
or Inputs
Analog
Audio
Inputs
Channel
Outputs
14
16
