96 I/O Guide
12
Example Studio Setup without a Mixing Console
Example Studio Setup without a Mixing Console
Power Amp
and Speakers
Digital Inputs/Outputs
To DAT Recorder
DAT Recorder
ADAT
Optical in/out
to ADAT
Analog
Audio
Outputs
Analog
Audio
ins/outs
Other Effects Devices
Digital Effects Device
(set to external sync)
Mic, Preamp,
Direct Box, Synth, etc.
Analog
Audio
Inputs
15
17
Table of Contents
Table of Contents
