96 I/O Guide12
6 Remove the five screws on the front plate of
the card to be removed.
7 To discharge any static electricity, touch the
power supply casing. It is a good idea to do this
often, throughout the process.
8 Pull the card out by gripping the edges be-
tween your thumb and forefinger on each side.
Pull straight back, lifting very slightly to avoid
contact between components on the underside
of the card and the 96 I/O back panel faceplate.
9 Place the card immediately in an anti-static
bag and send it to Digidesign according to in-
structions from Digidesign Customer Support.
Hardware Setup Changes After
Removing a Card
The Hardware Setup dialog reflects the removal
of an I/O card by settings corresponding inputs
and outputs to None. The remaining inputs and
outputs will function normally.
Touching power supply casing to discharge any
static electricity
When you remove a card, pay particular
attention to keeping components on the sur-
faces of the card from bumping into any of
the internal components or the back panel on
the 96 I/O.
