DigiPos Retail Active 8000 - Rear Side Components

Overview
3
Rear Side Components
No. Name
1 PCI-1 slot
2 Mouse port
3 Keyboard port
4 VGA port
5 DVI port
6 RJ45 LAN port
7 Two USB ports
8 Two 12V Powered USB ports
9 24V Powered USB port
10 Four COM ports
11 Cash drawer port
12 24V DC output
13 External power input
3 1
4 2
6 5
12V12V 24V
CASH DRAWER
POWERED RS232
PCI
DVI
EXTERNAL
POWERED INPUT
24VDC
OUTPUT
POWERED USB
5 7 8 9 121110 131 2 3 4 6
