Digital Acoustics IP7-FX - LED Indicators

Page 6
LED Indicators
Intercom LEDs
There are four LEDs present on the curved bezel on the front of the product.
• The blue LED indicates that the IP7-FX has powered up.
• The three red LEDs indicate status of the unit.
LED
Description
Ready
Indicates whether the unit has connected to a Server
Link
Indicates whether the unit has a valid network Connection
Active
Indicates whether audio is being transmitted or received
LED Status Table
Description
Ready
Link
Activity
Normal operational mode. Intercom can
communicate with its Server
On
On
Off
Playing Audio
On
On
Flashing
Playing Broadcast Audio
Fast Flash
20x per
second
On
Flashing
Sending Audio
On
On
On
Attempting to connect to make a
connection to a Server or unit has not
been configured
Flashing 4x
per second
On
LAN connection is inactive. The RJ45
may be unplugged
Flashing 4x
per second
Off
Device has reported its configuration on
a discovery request or connection. Fast
flash will stop after 20 seconds
Fast Flash
20x per
second
On
LAN Connector LEDs
On the Ethernet 10/100 RJ-45 connector:
• The Green LED tracks to the Ready LED
• The Yellow LED tracks to the Link LED
On the Port 2 10/100 RJ-45 connector
• The Green LED tracks to network transmit activity
• The Yellow LED tracks to network receive activity
