Digital-Ally DVM-800 User Manual

860-00186-00 Rev J
Digital Ally Inc.| Specifications
9-3
LICENSE PLATE BACKUP CAMERA
(OPTIONAL)
FOV: 95° (V) x 125.8° (H) x 155.4° (D)
Fixes focus lens
DWM Wireless Microphone
SYSTEM RANGE:
3000 feet typical LOS
COMMUNICATION:
Bidirectional
MICROPHONE SENSITIVITY:
-30dB, Maximum Input SPL 110dB
POWER CONSUMPTION:
External 12VDC, 190mA typical
SIZE:
DWM Cradle 2.75in x 2.99in x 3.15in (70mm x 76mm x 80mm)
DWM Microphone 2.5in x 1.8in x 0.94in (64 mm x 46 mm x 24 mm)
WEIGHT:
DWM Cradle 233g
DWM Microphone 74g
BATTERY:
Internal Li-ion 3.7V/1800mAh cell
20 hours In Use with full charge, 14 days Standby
4 hours charge time
FREQUENCY:
DWM-928 900MHz FHSS, 50 possible channels
DWM-868 800MHz FHSS, 50 possible channels
FREQUENCY RESPONSE:
200 ~ 4000Hz +/- 3 dB Audio
Media Storage
CAPACITY
External SD Card Support: 8/16/32 GB, Class-10, commercial grade 80 R MB/s, 50 W MB/s
SECURE MEDIA ACCESS
Optional tamper resistant screw can be installed in the access door, requiring the corresponding
security key to unlock the access door. (included with the DVM)
PRE-EVENT BUFFER
Up to 30 seconds for each of the two recording channels, adjustable in 6 second increments
Interface Box
DIMENSIONS
57mm (2.24in)(D) x 29mm (1.14in)(H) x 110mm (4.33in)(L)
INPUT SENSORS
Six customizable multi-purpose input sensors.
OPERATING VOLTAGE
13.8VDC
OUTPUT ALARM
One (1) normally open, active low output trigger, 2A maximum current
OPERATING TEMPERATURE
-20° to +70° C
STORAGE TEMPERATURE
-40° to +80° C
RADAR SUPPORT
9 Pin Serial Female (additional cables required)
*Specifications subject to change without notice*
