- 3 -
Upgrading from a
Mega 350,450, or Elite 500
If you are upgrading from a Mega 350, 450 or an
Elite 500 you will find the Mega 475 is similarly laid out.
The Keypad is the same and the screens are laid out in the
same four-line fashion. For the most part, the six blue
function keys; BRKT, Setup, Next, Clear, Up Arrow and
Down Arrow, work the same. Switching between Bracket
and Pro is also done in the same fashion as the earlier units.
Pressing the Setup key followed by the number 9 key sets the
unit in Pro Mode. Pressing the Bracket key (BRKT) sets the
unit in Bracket Mode.
While there are new features in the Mega 475, the
biggest change is the ability to directly control our full line
of V2 Dial Display boards. Just enter a new value for Your
Dial and the number is automatically displayed on the Dial
Display Board.
The Mega 475 also has the Set and Go Push-button
Mode. This Push-button Mode uses the press of one button
to apply the Transbrake solenoid. Then on the press of a
second button the timing starts counting down.
Even if you feel very comfortable with how the
earlier boxes work, it is recommended you review the
following upgrades to these features.
S.L.E. Starting Line Mode Page 34
Pro Shift Control Page 22
Replay Tach Page 47
Push-button Mode 5 Page 29
Dial Board Control Page 43
Wiring Dial Board Page 65
