5) S Value modification
Picture 3-24 Enter the status of modifying default S value
6) Select G coordinate system
Under “READY”, press the key till the Coordinate System is highlighted. It will display G54,
….G59 or MACH (stands for Machine Coordinates).
Use and to choose your desired Coordinate System. Position values will be displayed
for X, Y, Z and A. The Enter key confirms the Coordinate System you chose.
Use the key to highlight S. If you click or an Edit Window will appear
Choose your desired Feed speed and confirm with Enter.
Page -31Digtital Dream 4 Axis Motion Controller DDCS V2.1 User’s Manual
