Digital Dream DDCS V2.1 User Manual

The front panel consists of 17 user keys and the 4.3’’ (480*272) LCD. The rear side provides screw termi-
nals for power (18-32V), input signals, spindle control, pulse and direction for 4 stepper/ servo drives, MPG,
four programmable interfaces as well as an USB input. Please see the reference picture 1-3 and picture 1-4 in
detail.
Picture1-3 Front panel
Picture 1-4 Rear view
4.3'' Screen
17 user’s keys
Input Ports
Spindle&output Ports
Stepper/
Servo Ports MPG Ports
Power Supply
18~24VDC
USB Port
Page -3Digtital Dream 4 Axis Motion Controller DDCS V2.1 User’s Manual

Digital Dream DDCS V2.1 Specifications

General

Brand	Digital Dream
Model	DDCS V2.1
Category	Controller
Language	English
