1–2 DECserver 90M Owner’s Manual
Figure 1–1 shows a typical DECserver 90M configuration in a ThinWire Ethernet
LAN.
Figure 1–1: DECserver 90M Connection
LKG-6737–92I
Personal
computer
TD/SMP
terminal
Personal
computer
Printer
TerminalTerminalTerminalTerminal
DECserver 90M
IP router/
gateway
ULTRIX host
UNIX host
DECnet
router
MS-DOS
host
ThinWire Ethernet
OpenVMS
host
