A–4 DECserver 90M Owner’s Manual
A.4 DECserver 90M Connector Pin Out
Pin out for the DECserver 90M was designed for compatibility with Open
DECconnect. Figure A–1 shows the circuit connections for each port.
Figure A–1: Port Circuit
LKG-6741–92I
1
2
3
4
5
6
7
8
Rcv Gnd
Rcv
Tx Gnd
CTS
RTS
Tx
DTR
DSR
MJ8
EIA
423
Recv’r
EIA
423
Driver
EIA
423
Driver
EIA
423
Recv’r
NC
