13 | VMAX960H CORE™ Digital Video Recorder
No.
Name
Description
1
Video-In
Camera Inputs (NTSC/PAL)
2
Audio-In
Audio Input Device (with Amplifier)
3
Audio-Out
Audio Output Device (with Amplifier)
4
Video-Out
Main Composite Monitor Output
5
Spot-Out
Spot Composite Monitor Output
6
USB Port
USB 2.0 Port for Mouse Operation, Backup Device, or Firmware Update
7
HDMI Port
HDMI Output
8
LAN Port
100Mbps RJ45 Ethernet Connection Terminal
9 Power Input
Power Supply Connection
4 & 8 Channel Models: 12 VDC at 3.33Amps
16 Channel Model: 12VDC at 6.67Amps
10
Sensor Input
Sensor Input
11
Alarm Output
Alarm Output
12
RS-485 Port
For PTZ Dome Camera or External Keyboard Controller Connection
Note
Carefully check whether the specifications of the peripheral devices match the DVR’s specifications.
