Connections
The DF-7 Distortion Factory
™
is
equipped with a single INPUT and
a highly powerful set of outputs that
can be connected to both an amplifier
OUT 1 (AMP) and a mixer OUT 2
(MIXER) simultaneously or
configured so both OUTs can be
connected to two mixer channels
(Mode 2 stereo) or to two amps
(Mode 3 stereo).
Flexible Output Mode LED OUT 1 OUT 2
Mode One 1 Flash Amp Mono Mixer CIT Mono
Mode Two 2 Flashes Mixer CIT Stereo Mixer CIT Stereo
Mode Three 3 Flashes Amp Stereo Amp Stereo
Flexible Output Mode
™
Operations
