DigiTech QC1938 User Manual

User Manual
67
/
76
Burst
Types of
N Cycle, Infinite
Number of cycles
1~1024
Trigger source
Manual
Trigger input signal source
Level
CMOS
Probe compensator output
Output Voltage, typical
5V
Frequency, typical
1kHz±1%
General Specifications
Display
Display Type
7 inchs TFT (diagonal liquid crystal)
Display Resolution
800 (horizontal) * 480 (vertical) pixels
Display type
Point, vector
Waveform brightness
Adjustable
Grid type
Optional
Grid brightness
Adjustable
Screen brightness
Adjustable
Persist
1s, 5s, 10s, 30s, infinite
Interface
Standard interface
USB Host, USB Device
Power Supply
Supply Voltage
100-120VAC
RMS
(±10%), 45Hz to 440Hz, CATⅡ
120-240VAC
RMS
(±10%), 45Hz to 66Hz, CATⅡ
Power Consumption
<15W
Fuse
T2A 250VAC 4*8
Environmental
Operating Temperature
0 to 50 °C (32 to 122 °F)
Storage Temperature
-40 to +71 °C (-40 to 159.8 °F)
Humidity
≤+104℉(≤+40℃): ≤90% relative humidity
106℉~122℉ (+41℃ ~50℃): ≤60% relative humidity
Cooling Method
Convection
Altitude
Operating and Nonoperating
3,000m (10,000 feet)
Random Vibration
0.31g
RMS
from 50Hz to 500Hz, 10 minutes on each axis
Nonoperating
2.46g
RMS
from 5Hz to 500Hz, 10 minutes on each axis
Mechanical Shock
Operating
50g, 11ms, half sine
Mechanical
Dimension
318 x 110 x 150mm (L x W x H)
Weight
1900g
Appendix B: Accessories
All the following accessories are available by contacting your local
digitech
distributor.
