12
Pressure or Aftertouch), L - 1 (LFO1), L - 2 (LFO2), or DYN (Dynamic).
NOTE: Make sure you store any changes you make. See pg. 13 for more information
SETTING UP AN LFO OR DYNAMIC MODIFIER
To link an LFO to a parameter, please do the following:
1. Press the <FX Edit> button until you reach the modifiers edit mode. The modifiers icon begins to flash in
the bottom right corner of the screen.
2. Use the <Next Page> and <Prev Page> buttons to scroll to Page 9. The display reads:
3. Press the <1> button and use the <Data> wheel to select which LFO you want to adjust.
4. Press the <2> button and use the <Data> wheel to change the selected LFO's waveform. You can select
SINe, TRIangle, SPecial1, SPecial2 or SPecial3. Refer to pg. 19 for Waveform information.
5. Press the <3> button and use the <Data> wheel to adjust the speed of the LFO cycle.
The assigned parameter now follows the modulating waveform of the LFO you selected. See pg. 19 for waveform
diagrams.
To link a Dynamic Modifier to a parameter, please do the following:
1. Press the <FX Edit> button until you reach the modifiers edit mode. The modifiers icon begins to flash in
the bottom right corner of the screen.
2. To adjust the settings of the dynamic modifier, use the <Next Page> and <Prev Page> buttons to scroll
to Page 10. The display reads:
3. Press the <2> button and use the <Data> wheel to adjust LoThrs. This control sets the threshold above
which dynamic modification of the parameter begins.
4. Press the <3> button and use the <Data> wheel to adjust HiThrs. The HiThrs control sets the point at
which maximum parameter modification occurs.
5. Press the <4> button and use the <Data> wheel to select which input (1 - 4) you wish the modifier to lis-
ten to, or follow.
