33
SELECTABLE OUTPUT LEVEL MODE
The Studio Quad 4 offers you the ability to set your output level (-10 or +4dB). This option can be obtained within
the utility menu and the procedure is as follows:
1. From Program mode, press the <Utility> button and the use the <Next Page> or <Prev Page> buttons
to move to page 6 of the Utility menu and the display will appear as follows:
2. Press the <4> button to select the output level parameter and then use the <Data> to select either a +4
dBv or -10 dBu output. Once the desired output level has been selected, you can exit the Utility menu by
pressing the <Program> button.
HARMONY TUNING REFERENCE
When using Harmony intelligent pitch shifting, the Reference note pitch is set at A=440. If you wish to change the
reference note, you can access this function in the Utility menu. Reference can be set from A=427 to A= 453. The
procedure is as follows:
1. Press the <Utility> button and scroll to page 7 of the Utility page using the <Prev Page> or <Next
Page> buttons. The display reads:
2. Using the <Data> wheel, you can modify the Reference note anywhere from A=427 to A=453.
3. To exit Harmony Tuning Reference, press the <Program> button.
