Envelope Filter
Vocoder
Stereo Sampler
Sampler
Compressor
Gate
Vocal Eliminator
ThshO Sets the level at which the gate begins to open at the rate set by ATTACK. Both THSHO and THSHC
are independent controls. This gives you the option to do nifty stuff like setting THSHO higher than
THSHC, which could be used to let guitar notes sustain longer while still retaining the noise-gating
characteristics of the gate when closed.
ThshC Sets the level at which the gate begins to close at the rate set by RELEASE. Both
THSHO and THSHC are independent controls. THSHC cannot be set higher than THSHO.
Thsh Sets the minimum input level at which the compressor will engage
Ranges from -27 to 0.
Ratio Controls the amount of gain reduction applied to the input signal.
Ranges from 1.5 to 40.
Gain Controls the amount of gain that can be added to a signal after it has been compressed.
Ranges from 0 to 200%
Attack
Controls how quickly the gate or compressor opens after the signal level reaches THSH.
Varies from 0 to 2 seconds (Noise gate), Fast or Slow (Compressor).
Release
Determines how quickly the gate closes after the signal level falls below THSHC, or how
quickly the compressor disengages. When used in conjunction with long HOLD settings, this control
can be used to further prevent stuttering, or to make the closing of the gate less obtrusive.
Varies from 0 to 2 seconds (Noise Gate), Fast or Slow (Compressor).
Hold
The setting of HOLD determines how long the gate remains open after the signal level falls below THSHC.
Long HOLD settings can be used to prevent the gate from "stuttering", or opening and closing rapidly,
during soft passages when average signal levels are just above or below the THSHC setting. Varies
from 0 to 500 milliseconds.
Delay
Sets the amount of Delay before the Gate or Compressor engages. Ranges from 0.1 to 10
milliseconds.
PARAM. DESCRIPTION
Other Effects
✓
✓
FX Level Controls the overall effect level of the selected effect. Varies from OFF to 100%.
Dry Level Controls the dry level that is used in the selected effect module. Varies from OFF to 100%.
Balance Sets the dry path level within the Envelope Filter effect. Range is -99(all left) to 99 (all right).
Attn
Adjusts how far the signal level is lowered (attenuated) when the gate is closed. The higher you set
ATTN, the lower the noise floor of the source when the gate is closed. Varies from 0% to 100%.
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Loop This parameter turns the Sampler loop On or Off.
✓
✓
✓
✓
Over Dub This parameter (when turned On), allows you to record over the existing sample.
✓
✓
✓
RecPb This parameter sets the sampler to either Record or Playback mode.
✓✓
Trig This parameter (When pressed), triggers the sampler to record or play back.
✓✓
Start Time Sets the time before recording begins after the sampler has been triggered with in the maximum
5.0 or 2.5 (Stereo Sampler) seconds of sample. Range: 0ms to 5.0 seconds maximum
(Sampler) or 2.5 seconds Stereo Sampler.
✓✓
End Time Sets the time when recording ends after the sampler has been triggered within the maximum 5.0 or 2.5
(Stereo Sampler) of sample. Range: 0ms to 5.0 seconds maximum (Sampler) or 2.5 seconds
Stereo Sampler.
✓✓
AudTrg This parameter activates the Audio Trigger function of the Sampler. When engaged, Sampler can be
triggered by an incoming audio signal. Settings are On or Off.
✓✓
AudThr This parameter sets the threshold of which the audio trigger will be activated. Range is from -30 to 0.
The higher the Threshold is set, the higher the input signal must be set to trigger the sampler.
✓✓
Direct This is the direct (Dry) signal level that passes through the Sampler. Range is from Off to 100%.
✓✓
Sampler Lvl This is the output level of the Sampler. Range is from Off to 100%.
✓✓
Band Freq This parameter is used to select different frequency bands for the Vocoder effect. Range is from
25.0 Hz to 20.0 kHz.
✓
Width Sets the width of the selected Frequency band. Range is from. 0.08 (Narrow) to 4.00 (Wide).
✓
Level Sets the cut or boost of the Vocoder frequency band and ranges from. -12 to 12 dB.
✓
VceLvl This parameter sets the input Voice level entering the Vocoder or Eliminator. Range is from Off to 100%.
✓
Carrier Lvl This parameter sets the input Carrier (Synth) level entering the Vocoder. Range is from Off to 100%.
✓
Sibilance Sets the amount of "Essing" that is passed through the Vocoder. Range is from Off to 100%.
✓
Type (Vcder) Allows you to select any one of the five different Vocoder settings in the Quad 4.
✓
Gain Controls the input gain of the Vocoder effect. Range is from Off to 100%.
✓
Output Lvl Controls the overall output level of the selected the effect. Range is from Off to 100%.
✓
Sensitivity Adjusts the sensitivity of the detection of the envelope filter. Higher sensitivity settings produces a
wider envelope filter range. Settings are Off to 100%.
✓
Type (V E) This parameter allows you to select one of four different Vocal Eliminator types. Types are as follows:
1. Removes Lower Vocal Freqs. 2. Removes Medium Range Vocal Freqs. 3. Removes High Freqs and
4. Removes the Center channel signal.
✓
Voice Cut This parameter allows you to select the amount of Vocal signal that is removed in the Vocal Eliminator.
Range is from Off to 100%. A setting of 100% equals complete Vocal cut.
✓
✓
