DigiTech RP360 XP User Manual

83
RP360 / RP360 XP
EQ
EQ
The 3-band semi-parametric EQ is used to further shape your tone and provides low, mid, and high-
band controls, each with adjustable frequency and bandwidth�
Parameters
NAME
OPTIONS OR
RANGE
DESCRIPTION
ON/BYP ON, BYPASS Turns the effect on and off�
LOW LEVEL -12 dB to +12 dB Adjusts the level of the low frequencies (bass)�
LOW FREQ 60 Hz - 500 Hz Sets the center frequency of the low filter�
LOW BW
WIDE, MEDIUM,
NARROW
Sets the width of the low filter�
MID LEVEL -12 dB to +12 dB Adjusts the level of the midrange frequencies (mids)�
MID FREQ 300 Hz - 4 kHz Sets the center frequency of the mid filter�
MID BW
WIDE, MEDIUM,
NARROW
Sets the width of the mid filter�
HIGH LEVEL -12 dB to +12 dB Adjusts the level of the high frequencies (treble)�
HIGH FREQ 2 kHz - 8 kHz Sets the center frequency of the high filter�
HIGH BW
WIDE, MEDIUM,
NARROW
Sets the width of the high filter�

DigiTech RP360 XP Specifications

General

Type	Multi-Effects Processor
MIDI I/O	No
USB	1 x Mini-B
Effects Types	Delay, Reverb, Modulation, Distortion
Presets	198 (99 factory, 99 user)
Looper	Yes (40 seconds)
Inputs	1 x 1/4" instrument
Outputs	2 x 1/4"
Footswitches	3
Expression Pedal	Yes (built-in)
Power Supply	9V DC adapter (included)
Cabinet Models	20+
