DigiTech Whammy DT User Manual

Page 19
Specifications
Instrument Input Type: 1/4” Unbalanced TS
Max Input Level: +5 dBu
Input Impedance: 1 MΩ
MIDI Input: 5-Pin Din
Footswitch Input: 1/4” TRS – for use with optional FS3X Footpedal
Output Type: 1/4” Unbalanced TS
Max Output Level: +10 dBu
Output Impedance: 1 kΩ
Sample Rate: 44.1 kHz
Frequency Response: 20 Hz to 20 kHz
Signal to Noise Ratio: > -105 dB (A weighted); ref = max level, 22 kHz bandwidth
THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
A/D Conversion: 24 bit
D/A Conversion: 24 bit
Pitch Bend Range: +2/-3 Octaves
Detune Range: -4 to -30 cents
Drop Tune Range: 1-7 Semitones, Octave, Octave + Dry
Power Consumption: 2.6 Watts (< 288 mA @ 9 VDC)
Power Requirements: 9 VDC External Adapter
Power Adapter: PS0913DC-01 (US, JA, EU)
PS0913DC-02 (AU, UK)
Dimensions: 8.2” (W) x 7.73” (D) x 2.36” (H)
Shipping Weight:
4.5 lbs.

DigiTech Whammy DT Specifications

General

Bypass Switching	True Bypass
Technology	Digital
Expression Pedal	Built-in
Whammy Effects	Yes
Detune Effects	Yes
Harmonizer Effects	Yes
Effect Type	Pitch Shifter
Inputs	1 x 1/4"
Outputs	1 x 1/4"
Power Source	9V DC
Features	Drop Tune, Momentary Switch
Pitch Shifting Range	+/- 2 Octaves
