DigiTech Whammy DT User Manual

Page 2
Guided Tour
Detailed Description
1. WHAMMY Effect Switch
This switch turns the Whammy, Harmony or Detune effect on and off.
2. Whammy Effect Status LED
This LED lights to indicate the Whammy, Harmony or Detune effect is on. When the Whammy effect is bypassed,
this LED will be off.
3. Whammy LEDs
One of these LEDs will light when a Harmony, Whammy or Detune effect is selected. Harmony effects have dry
signal added to the effect signal. Whammy and Detune effects do not have dry signal added to the effect signal.
4. Whammy Effect Selector Knob
This knob is used to select the Whammy (bend), Harmony intervals, or Detune range controlled by the expression
pedal.

DigiTech Whammy DT Specifications

General

Bypass Switching	True Bypass
Technology	Digital
Expression Pedal	Built-in
Whammy Effects	Yes
Detune Effects	Yes
Harmonizer Effects	Yes
Effect Type	Pitch Shifter
Inputs	1 x 1/4"
Outputs	1 x 1/4"
Power Source	9V DC
Features	Drop Tune, Momentary Switch
Pitch Shifting Range	+/- 2 Octaves
