3 RS485 interface

3.1 Connection diagram

(1) RS485 interface

This device can be ordered with an RS485 interface as an option.

Please refer to the Operating and Installation manual INSTALL-148

for the type designation.

Connect the interface line shielding to earth on one side in the

switch cabinet.

N(L-)

L1(L+)

RxD/TxD

(1)
