DigiTrace TCONTROL-CONT-03 User Manual

4 Modbus addresses
22
4.2 Set point values
0x0024 INT R/O Limit comparators 1...2
Bit 0 Limit comparator 1 (= 0x0001)
Bit 1 Limit comparator 2 (= 0x0002)
0x0025 INT R/W Control of the binary outputs (individual)
Bit 0 + Bit 8 Output K1 (= 0x0101)
Bit 1 + Bit 9 Output K2 (= 0x0202)
Bit 2 + Bit 10 Output K3 (= 0x0404)
Bit 3 + Bit 11 Output K4 (= 0x0808)
0x0026 FLOAT R/O Analog input [mV]
0x0028 FLOAT R/O Internal Pt100 [Ohm]
0x002A INT R/O Sampling cycle time
0x002B FLOAT R/O Analog input [displayed value]
0x002D FLOAT R/O Internal analog value 1
0x002F FLOAT R/O Internal analog value 2
0x0031 FLOAT R/O Controller, ramp limit value
0x0033 FLOAT R/O Controller, actual value, FILTERED
0x0035 FLOAT R/O Controller, actual value, UNFILTERED
0x0037 FLOAT R/W Controller set point value
0x0039 FLOAT R/O Controller, output value display
0x003B FLOAT R/O Controller, output value, HEATING
0x003D FLOAT R/O Controller, output value, COOLING
0x003F FLOAT R/O Controller, control difference
0x0041 FLOAT R/O Controller, control deviation
0x0043 INT R/O Controller, switching state, HEATING
0x0044 INT R/O Controller, switching state, COOLING
0x0046 INT R/O Output value, manual mode
0x0047 LONG R/O Timer run time
0x0049 LONG R/O Residual timer time
0x004B INT R/O Timer status
Bit 1 Timer stopped (= 0x0002)
Bit 5 Timer runs (= 0x0020)
Bit 6 Timer end (= 0x0040)
Bit 15 Timer signal (= 0x8000)
Address Data type/
bit number
Access Signal designation
0x3100 FLOAT R/W Set point value W1
0x3102 FLOAT R/W Set point value W2
Address Data type/
bit number
Access Signal designation
