DigiTrace TCONTROL-CONT-03 User Manual

3 RS485 interface
20
3.2 Configuration
The following table shows the possible Modbus interface settings to be
carried out in the configuration level (ConF
➔ IntF) and/or in the setup program.
v
For more detailed information about configuration, please refer to
the Operating and Installation manual INSTALL-148.
Symbol Value/
Selection
Description
Baud rate
bdrt
0
1
2
9600 bps
19200 bps
38400 bps
Data format
dFt
0
1
2
3
8 data bits, 1 stop bit, no parity
8 data bits, 1 stop bit, odd parity
8 data bits, 1 stop bit, even parity
8 data bits, 2 stop bits, no parity
Device address
Adr
0…1 …255 Address in data network
Addresses 0 and 255 are reserved for specific
purposes and should not be used here.
Minimum
response time
(Setup) 0…500ms Minimum time period that elapses between the
request of a device in the data network and the
response of the controller (can only be adjusted
via the setup program).
Factory settings are shown bold.
H
When the communication takes place via the setup interface, the
RS485 interface is inactive.
