4 Modbus addresses
4.3 Controller parameters
4.4 Configuration
Address Data type/
bit number
Access Signal designation
0x3000 FLOAT R/W Controller parameter XP1
0x3002 FLOAT R/W Controller parameter XP2
0x3004 FLOAT R/W Controller parameter TV
0x3006 FLOAT R/W Controller parameter TN
0x300C FLOAT R/W Controller parameter CY1
0x300E FLOAT R/W Controller parameter CY2
0x3010 FLOAT R/W Controller parameter XSH
0x3012 FLOAT R/W Controller parameter XD1
0x3014 FLOAT R/W Controller parameter XD2
0x3016 INT R/W Controller parameter TT
0x3017 INT R/W Controller parameter Y0
0x3018 INT R/W Controller parameter Y1
0x3019 INT R/W Controller parameter Y2
Address Data type/
bit number
Access Signal designation
0x0053 FLOAT R/W Ramp function, ramp rate
0x0055 FLOAT R/W Filter time constant (digital filter)
0x0057 FLOAT R/W Limit comparator 1 Alarm value AL
0x0059 FLOAT R/W Limit comparator 1 Hysteresis
0x005D FLOAT R/W Limit comparator 2 Alarm value AL
0x005F FLOAT R/W Limit comparator 2 Hysteresis
0x0063 LONG R/W Timer value
0x0065 LONG R/W Service limit value
0x0067 TEXT4 R/W Alarm text
0x0069 LONG R/W Service counter
