4 Modbus addresses
24
4.5 Commands
Address Data type/
bit number
Access Signal designation
0x004D INT W/O Binary functions CONTROLLER
Bit 0 Self-optimization start (=0x0001)
Bit 1 Self-optimization abort (=0x0002)
Bit 2 Manual operation (= 0x0004)
Bit 3 Automatic operation (= 0x0008)
Bit 4 Controller off (= 0x0010)
Bit 5 Manual mode inhibit (= 0x0020)
Bit 6 Ramp stop (= 0x0040)
Bit 7 Ramp abort (= 0x0080)
Bit 8 Ramp restart (= 0x0100)
Bit 9 Timer start (= 0x0200)
Bit 10 Timer abort (= 0x0400)
Bit 11 Timer stop (= 0x0800)
0x004E INT W/O Binary functions OPERATION
Bit 0 Keyboard inhibit (= 0x0001)
Bit 1 Configuration and parameter level inhibit
(= 0x0002)
Bit 3 Display OFF (= 0x0008)
Bit 5 Text display (= 0x0020)
0x004F INT W/O Binary functions TIMER
Bit 9 Timer start (= 0x0200)
Bit 10 Timer abort (= 0x0400)
Bit 11 Timer stop (= 0x0800)
0x0050 INT R/W Set point value toggling
Bit 0 Set point value 1 (= 0x0001)
Bit 1 Set point value 2 (= 0x0002)
