©2007 Digitrax, Inc www.digitrax.com 14
commands.
Closed,the DS64 accepts computer commands only.
DCS100 owners - this is also known as the Bushby bit.
Option Switch 11-Operate Local Routes Using DS64 Inputs
OpSw11 This option is not yet implemented. Do not change.
Option Switch 12-Forced Output on High
OpSw 12 determines weather the local inputs are set to toggle a turnout
from one state to the other or to force the state to closed or to thrown.
Thrown: (factory default) The local "S" input toggles the state of the out-
put with each trigger (high) between CLOSED and THROWN.
The local "A"input if high will send a General Sensor Message to
LocoNet. A trigger on "A" does not have any effect on the output.
Closed: The local "S" input if high will force the output state to
"CLOSED." The local "A" input if high will force the output state to
"THROWN". No sensor capability is available with this setting.
Option Switch 13-Set Inputs for Sensor Message and Turnout Setting
Thrown: (factory default) Disabled.
Closed: All 8 inputs "A" and "S" are set for sensor messages to LocoNet.
As an example, if input S2 goes high, then a LocoNet message is sent.
When that input goes low, another LocoNet message is sent. All 8 inputs
work the same way. These sensor messages can be used with DCC soft-
ware such as Winlok, Railroad&Co., etc. to generate an action such as
updating a display based on track occupancy or manually with a local
push button.
Additionally the input will also control the output state per OpSw12. If
OpSw 12=thrown, the "S" input will toggle the output. If OpSw
12=closed, input "S" will force the output state to CLOSED while the
"A" input will force the output state to THROWN.
