Digitrax DS64 - Option Switch 14-Command Priority to Loconet or Track; Option Switch 15-Set Inputs for Sensor Message Only; Option Switch 16-Enable;Disable Local Routes; Option Switches 17-20 Setting up a Crossing Gate

©2007 Digitrax, Inc www.digitrax.com 15
Important Note: The Closed Setting will only work if OpSw 15 is thrown
(Disabled).
Option Switch 14-Command Priority to LocoNet or Track
OpSw 14 determines whether LocoNet or Track commands have priority. This
is useful when using DS64 with a non-LocoNet DCC systems.
Thrown (factory default) the DS64 obeys switch commands as a priority
from LocoNet or alternately the TRKA and TRKB terminals if LocoNet
is not connected.
Closed the DS64 obeys switch commands from the DCC TRKA and
TRKB terminals only.
Option Switch 15-Set Inputs for Sensor Message Only
OpSw 15 This option is not yet implemented. Do not change.
Option Switch 16-Enable/Disable Local Routes
Thrown (factory default) enables operation of routes.
Closed disables operation of routes.
Option Switches 17-20 Setting Up a Crossing Gate
A crossing gate can be set up using a DS64 in slow motion mode (OpSw 01
= Closed). See Figure 3 for hook up diagram.
OpSw 17
Thrown (factory default) the Crossing Gate feature is disabled.
Closed a high on either of the Inputs (A1 or S1) related to Output ‘1’
causes output ‘1’ to blink at a rate defined in OpSw Op Switches 02-05.
OpSw 18
Thrown (factory default) the Crossing Gate feature is disabled.
Closed a high on either of the inputs of output ‘2’ (A2 or S2) causes out-
put ‘2’ to blink at a rate defined in Op Switches 02-05.
OpSw 19
Thrown (factory default) the Crossing Gate feature is disabled.
Closed, a high on either of the inputs of output ‘3’ (A3 or S3) causes out-
put ‘3’ to blink at a rate defined in Op Switches 02-05.
OpSw 20
Thrown (factory default) the Crossing Gate feature is disabled.
Closed, a high on either of the inputs of output ‘4’ (A4 or S4) causes out-
