6
Components and Features
1-USB Port Print Server
˙1 USB2.0 port
˙Fast Ethernet network port: RJ-45 for 10Base-T or 100Base-TX
˙1 LED to indicate Status: Orange
˙1 LED to indicate USB port: Green
˙1 LED to indicate WLAN status: Orange
˙Built-in WPS Button
˙Built-in Reset Button
˙One Setup CD for Windows 95/98/Me/NT/2000/XP/2003/Vista/7, User’s Guide
˙One external AC power adapter
˙One Quick Installation Guide
LED Indicators
LED State Indication
Status
On (Orange)
When power switched on, the Status indicator will flash five
times, and then on. The LAN port is linking also
Blinking (one time
per second)
When power switched on but LAN port is not linking
Blinking (several
times per second)
Data transmitting
USB On (Green) Connect with USB2.0 printer
WLAN
On(Orange) WLAN enabled
Blinking Data transmitting
Before you start, you should prepare the following items:
One Windows-based computer with print server setup CD
One printer with a USB port
One USB printer cable
