▓ Network
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP,
ICMP, SMTP, FTP, HTTP, RTP, RTSP
Frame Rate NTSC:30, PAL:25
Number of Online Users 10
Security Multiple user access levels with password
Web management software YES (Control up to 16 network cameras simultaneously)
▓ Video / Audio
Video Compression MPEG4 / MJPEG
Video Remote Control YES
Video Adjustment Brightness, Contrast, Saturation and Hue
Audio Compression NO uLaw , 128kbps
Audio Input NO Built-in Microphone, External Microphone Input
Audio Output NO YES
▓ Camera
Image Sensor 1/3.6" image sensor
Pixels 738(H) x 480(V)
Lens f3.6mm f4.6mm f3.6mm
F-number F2.0
Viewing Angle 80° 55.6° 80°
Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.
IR LED NO YES
Min Illumination 1 Lux / F2.0 1 Lux / F2.0; 0 Lux (10m IR ON)
Video Output 1.0 Vp-p. 75Ω
BLC AUTO
White Balance ATW
▓ Others
Remote Control YES
Motion Detection YES
Alarm and event Notification NO Image upload over FTP and Email
General I/O NO Alarm in x1
Power DC12V, 0.5A DC12V, 1A
Operating Temperature 0~40℃
Humidity 85%
Minimum Web Browsing Requirements
‧Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
‧256 MB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows XP, Windows 2000 Server, ME, 98, DirectX 9.0 or later
‧Internet Explorer 6.x or later
Dimension (L x W x H)** 152.5 x 115.2 x 40.2 mm (6.00” x 4.54” x 1.58”)
Shipping Weight 812g (1.79 lbs) including mounting bracket and power supply
Indoor / Outdoor Application Indoor
* The specifications are subject to change without notice.
** Dimensional tolerance: ± 5mm
‧ Dimensions: 152.5 (L) x 115.2 (W) x 40.2 (H) mm
