6. Introduction
Front View
8 ports selection switches
16 ports selection switches
No. Section Function
1
Port
Selection
Switches
Press a switch button to access the computer attached to
its corresponding port. The internal buzzer beeps, it
means that the switching action is performed correctly,
the selected port LED will light up as well.
2 Port LEDs
The port LEDs are built into the Port Selection Switches.
The upper ones are the On Line LEDs.
The lower ones are the Selected Port LEDs:
• The On Line LEDs light RED to indicate that the
computer attached to the corresponding port is up and
running.
• The Selected LEDs light GREEN to indicate that the
computer that attached to the corresponding port is
the one that has the KVM focus.
3 Reset
If KVM has no responding, plug needle or ballpoint pen
into the hole to reset KVM
