Digitus DS-55309 User Manual

Spezification
Supported video resolution
Model: DS-55309
480p@60Hz, 576p@50Hz,
720p@50/60Hz, 1080p@50/60Hz
Supported audio formats
LPCM
HDMI connector
Type A, Female, 19-pin
HDbitT version
1.3e
Latency
<220ms
Input and Output
TMDS signal
0.7～1.2Vp-p(TMDS)
Input and Output
DDC signal
5Vp-p(TTL)
Transmission distance
up to 30 m (free field of vision)
Voltage
power by HDMI port or USB cable
Power consumption
TX＜2.5W,
RX＜2W
ESD protection
1a (contact discharge) level 3
1b (air-gap discharge) level 3
International Standard: IEC61000-4-2
Operating temperature
(0°C ~ 60°C) 32°F ~ 140°F
Storage temperature
(-10°C ~ 70°C) -14°F ~ 94°F
Relative humidity
0 ~ 90% RH (Non-condensing)
Dimension
TX: 88.9(W) x38.99(D) x 15.17(H) mm
RX: 88.9(W) x38.99(D) x 15.17(H) mm
Material
Plastic
Weight
TX: 30g
RX: 30g
Colour
black

Digitus DS-55309 Specifications

General

Brand	Digitus
Model	DS-55309
Category	Extender
Language	English
