Dimension One Spas – Reflections Owner’s Manual
7
9. Remove the filter
lid(s) and then
remove the foam
blocks securing the
filter(s). Your spa
may have one or
two filters.
10. If your spa has two filters, remove the
UltraPure filter (see photo to the left) and
fill the spa with a hose in that canister.
Otherwise, remove the single filter and fill
the spa through that canister. (You can
see Filter Cleaning instructions in this
manual to learn more about removing
filters).
11. Fill the spa until the water
level is about six inches
below the top of the spa or
two inches above the
bottom of the tile line if your spa has tile.
12. Once the spa is filled, turn on the GFCI circuit breaker. Flashing dashed lines will appear for
30 seconds on the Display Window followed by the current water temperature (flashing).
The Topside Control Panel, shown below, will vary depending on the model of your spa.
13. Push the JETS Button twice (use the JETS 1 Button on multi-
pump spas) on North American 60Hz models to turn the
pump on to high speed. (Push it once on European 50Hz
models). Let the system run for 30 to 45 seconds to prime the
pump. Then push the button again to shut the pump off. If
your spa has two jet pumps, repeat the process using the
JETS 2 Button. Replace the bleeders once the pumps are
running properly.
If there is no jet action, then there is air trapped in the
plumbing lines. To eliminate the trapped air, turn the pumps
on and off several times to force the trapped air through
the pumps. If there is still no jet action, and the bleeder
valves have been open for some time, turn off the pumps
and loosen the top pump unions (see illustration in step 6)
slightly to let any trapped air escape. Re-tighten the pump
unions and turn the pumps on again. Turn the pumps on
and off several times until jets function properly.
