IMPORTANT REMARKS
For any installation problems please contact V2 S.p.A.
TEL. (+39) 01 72 81 24 11
V2 S.p.A. has the right to modify the product without
previous notice; it also declines any responsibility to
damage or injury to people or things caused by improper
use or wrong installation.
PLEASE READ THIS INSTRUCTION MANUAL VERY
CAREFULLY BEFORE INSTALLING AND PROGRAMMING YOUR
CONTROL UNIT.
•
This instruction manual is only for qualified technicians, who
specialize in installations and automations.
• The contents of this instruction manual do not concern the
end user.
•
Every programming and/or every maintenance service should
be done only by qualified technicians.
AUTOMATION MUST BE IMPLEMENTED IN COMPLIANCE
WITH THE EUROPEAN REGULATIONS IN FORCE:
EN 60204-1 (Machinery safety. electrical equipment of
machines, part 1: general rules)
EN 12445 (Safe use of automated locking devices, test
methods)
EN 12453 (Safe use of automated locking devices,
requirements)
• The installer must provide for a device (es. magnetotermical
switch) ensuring the omnipolar sectioning of the equipment
from the power supply. The standards require a separation of
the contacts of at least 3 mm in each pole (EN 60335-1).
• To connect flexible or rigid pipes, use pipefittings having the
IP55 insulation level.
• Installation requires mechanical and electrical skills,
therefore it shall be carried out by qualified personnel only,
who can issue the Compliance Certificate concerning the
whole installation (Machine Directive 98/37/EEC, Annex IIA).
• The automated vehicular gates shall comply with the
following rules: EN 12453, EN 12445, EN 12978 as well as
any local rule in force.
• Also the automation upstream electric system shall comply
with the laws and rules in force and be carried out
workmanlike. V2 S.p.A. declines any responsibility in
case of automation upstream electric system not complying
with the laws and rules in force and not carried out
workmanlike.
• The door thrust force adjustment shall be measured by
means of a proper tool and adjusted according to the max.
limits, which EN 12453 allows.
• We recommend to make use of an emergency button, to be
installed by the automation (connected to the control unit
STOP input) so that the gate may be immediately stopped in
case of danger.
• The use of MOOV-SEZ50 in dusty, saline or explosive
environment is forbidden.
DECLARATION OF CONFORMITY
V2 S.p.A. declares that the series of MOOV-SEZ50 actuators are in
conformity with the provisions of the following EC directives:
73/23/EEC electrical safety
93/68/EEC electromagnetic compatibility
99/05/EEC radio directive
98/37/EEC machine directive
Note: Declares that the above mentioned devices may not be ope-
rated until the machine (automated gate) is identified, CE-labeled,
and declared to be compliant to the specifications of Directive
89/392/EEC and following modifications.
The person in charge for the machine start-up must provide the
following records:
• Technical specification paper
• Declaration of conformity
•
CE-labeling
• Testing record
• Maintenance record
• Operation manual and directions
Racconigi 18 / 05 / 2007
V2 S.p.A. legal representative
A. Livio Costamagna
V2 S.p.A.
Corso Principi di Piemonte, 65/67
12035 RACCONIGI (CN) ITALY
tel. +39 01 72 81 24 11
fax +39 01 72 84 050
info@v2elettronica.com
www.v2home.com
TECHNICAL SPECIFICATIONS
MOOV-SEZ50
Power supply 230V - 50Hz
Absorbed power 100 W
Door Area < 8 m
2
Peak Force 500 N
Nominal Force 350 N
Average speed 11 cm/s
Lamp 230V - 50 Hz - 25W
Working temperature -20 ÷ +40 °C
Working cycle 30%
Protection IP20
Weight 10 Kg
Protection fuses
SOURCE= 2,5 A
LIGHT = 2,5 A
