dimos DIPRO-P4600 - Inside Tray Width; 4 Description; Overview

8
It is possible to make special profiles with two consecutive passes
D. Inside tray width
Inside tray width approximately 78 mm appears when profiling a standard tray.
Example: - Width of the sheet metal strip 650 mm (1)
- Width at bottom of tray 572 mm (2)
4. DESCRIPTION
A. Overview
A1
Input guide
A2
Control panel / Power supply
A3
Width fastening lever
A4
Entry guide locking bolts
650
572
(1)
(2)
EN
G
A1
A2
A3
A4
