1.7.1 Installation pack 1 - Space heating and Dimplex A-Class cylinder
No.
Description Part No.
1 A-Class heat pump A8M / A12M / A16M
10 Blanking plugs (x4, stored inside heat pump) 4592624105
Hydraulics Kit A ACCHYPK
2 User interface (UI) 1754600
3 ERES spring loaded by-pass valve (22mm comp. tting) 1755780
4 3-port diverting valve (28mm comp. ttings) 1755750
5 Pump - UPM GEO 25-85 180 (1500mm cable) 1755740
6 Isolation valves (1” swivel BSP to 28mm comp.) - Flow 1755760
7 Isolation valves (1” swivel BSP to 28mm comp.) - Return with strainer 1755770
13
2 x Circulation Pump Gate Valve 11/2” swivel to 28mm comp
2 x Washer 30.1x21x2mm
1756090
Dimplex A-Class cylinder kit, which includes;
8 A-Class cylinder with integrated buffer
9
Safety group DHW side; expansion vessel, hose and bracket, inlet group,
tundish
11 Drain
12 3x copper pipes - Pump to buffer / cylinder
14 Air vent
Pipe connections to coil, pipe, drain and vent.
Pipe connections to pump.
