Dimplex ASCARI MA12 - 3 Speed water pump

Ascari MA12 -p. 30 -
3 speed (I, II et III) water pump for adjustment to operating needs, depending on insulation and circuit
Electric datas
II
II
I
IIIIII
IIIIII
III
IIII
IIII
II
Speed
Nominal
output (W)
Nominal
intensity (A)
III
90 0,40
II
67 0,30
I
47 0,20
The boiler is factory set at pump speed 3, for lower pump speeds the selector in the centre of the pump may
be turned to 1 or 2 using a large flat bladed screwdriver.
2.19 - 3 Speed water pump
