Dimplex BF33ST/DX - Wiring Diagrams

WALL MOUNTED THERMOSTAT WIRING
DIAGRAM FOR 120/240 VOLT
(SEE SECTION C OR SECTION D FOR MAIN POWER CONNECTION)
16
FIREPLACE JUNCTION BOX
WALL
THERMOSTAT
RED
–
1
GROUND - G
RED
–
2
CONNECT
GROUND TO
WALL BOX
