FLAME OVERRIDE WALL SWITCH WIRING
DIAGRAM FOR 120/240 VOLT
(SEE SECTION C OR SECTION D FOR MAIN POWER C0NNECTION)
NOT AVAILABLE WITH NO HEAT INSTALLATION
FIREPLACE JUNCTION BOX
BLUE
–
4
WALL
SWITCH
BLUE
–
3
GROUND - G
18
