Manual Controls
Main Power Switch
Main on/off switch, energizes firebox and flame.
Mode Selector Switch
Select preferred feature:
Select “o” for flame only
Select “=” for heat/Purifire
TM
/flame
Select “-“ for Purifire
TM
only/flame.
Wall Mounted Controls
The fireplace can be installed with wall mounted controls. These controls include wall switches
and thermostats. (see installation guide for details)
Wall Mounted Switches
This model may be installed so that a wall mounted switch energizes the firebox and flame,
(Main Power Switch must be in the ON position). A wall mounted switch may also be
used to override the flame image, (Main Power Switch must be in the ON position in
coordination with any main power wall mounted switch). A wall mounted switch may
also be used to override the heater/Purifire
TM
option (Mode Selector Switch must be in
the “=” position).
Wall Mounted Thermostat
This unit may be installed so that a wall mounted thermostat can adjust the heat
temperature to your individual requirements. Please refer to thermostat manufacturers
operation Instructions. Mode Selector Switch must be set to “=” for thermostat to
control heater/Purifire
TM
.
Main Power
Switch
Mode
Selector
Switch
o Flame only
= Heat/flame
- Purifire
TM
only/flame
4
