5.1 Appendix 1 - Technical Specifications - Energy Meter
Ordering Codes
DOEE 054722
Voltage / Current
Input Voltage Range 100V to 255V AC, 50/60Hz
Voltage Accuracy +/- 1%
Voltage Resolution 0.1 Volt
Current Measurement Range 0.1 to 80A
Current Accuracy %1-/+ A08 ~A4 %5.1-/+ A4~A6.1
Current Resolution 0.01A
kWh, PF, kVAh kWh Accuracy +/- 1%
kWh Resolution 0.01 kWh
Power Factor Accuracy +/- 1%
Power Factor Resolution 0.01
kVAh Accuracy +/- 1%
kVAh Resolution 0.01 kVAh
Certification
Certification CE
Metering Standard Class 1 (Accuracy only)
Wireless Technology
Radio Technology Dimplex GFSK
Radio Frequency 868 MHz ISM Band
Channels 4 Channels (1 - 4)
Max Tx Power +13dBm
Rx Sensitivity -105dBm@25Kbps
Data Rate up to 25 kbits/sec
Wireless Range Indoor Range up to 50m
Outdoor Range up to 300m (direct line of sight)
Rated input power
Power Consumption 1 Watt
Physical
Dimensions (LxWxH) 231 x 125 x 48 mm
Weight 0.201 kg
Mounting Wall Mounting Flanges
Enclosure V0 Polycarbonate
Operating Temperature -20°C to +45°C
Operating Humidity up to 85% (non-condensing)
